Features:
- Lance move: Electric
- Automatic Strapping, cutting and welding
- Welding : Electric heat
- Detection for feeding not in position, no strap and strapping failure
Options:
- Strapping tension of 100Kgs
- Conveyor System
- Custom Made
Power |
3phase, 220/380/415/440, 50/60Hz |
Arch Size |
W1750 x H1600mm (other sizes made on request) |
PET Strap Width
PP Strap Width |
9,12,15,19mm
12,15,19mm |
Strapping Tension |
60~140Kgs |
Strapping Speed |
20 sec / Strap (exclude convey time) |
Sealing Method |
Heat Seal |
Air |
6 Kgf/cm2 (lance with electronic driven) |
Detection |
Detection for strap not in position
Detection for no strap
Detection for strap failure |
Machine Size |
L3079xW781xH1971mm |
|
|
|
|
|
|
|
